Servo motor encoder with UVW phase 12v 24v 30v 450w dc motor encoder

Servo motor encoder with UVW phase 12v 24v 30v 450w dc motor encoder

Add success, do you want to check your shopping cart?

Quick Details
Place of Origin:
Shanghai, China
Brand Name:
Model Number:
Servo motor encoder with UVW phase 12v 24v 30v 450w dc motor encoder
Position Sensor
Optical sensor
square-wave signal
Item Name:
Servo motor encoder with UVW phase 12v 24v 30v 450w dc motor encoder
External dameter:
Hollow shaft diameter:
8mm /6mm /10mm /12mm
up to 8192PPR
Protection grade:
Supply voltage:
DC5V & DC8-30V
Output mode:
NPN & voltage output & push-pull output & difference output
Outlet type:
wire out from side
Wire length:
140g per piece
Supply Ability
Supply Ability:
100000 Piece/Pieces per Month Servo motor encoder with UVW phase 12v 24v 30v 450w dc motor

Servo motor encoder with UVW phase 12v 24v 30v 450w dc motor encoder



1) Advantages

 1, Factory characteristic

------Customer Repurchase rate ≥ 85%

------Over 25 years experience engineer team in research and development

------ CE & ISO9001 & SGS Certification

 2, Encoder characteristic

   --- support for 4 poles, 6poles, 8pols,16 poles.

   --- Servo motor encoder with UVW

   --- Can be totally replaced OIH48-TS5214N500P4L65V encoder

3, Application: textile industry, packing machinery, production line, etc., for automation control.



2) K48- Series Specification



Items HENGXIANG K48-Series dc 12v 24v encoder gear motor factory best price
External dimensionsExternal diameter: 48mm
Thickness: 34mm
Hollow Shaft diameter: 6mm/8mm/10mm/12mm
Resolution 22;50;60;100;200;250;256;300;360;400;450;500;512;600;
Output phasePhase A,B,Z,U,V,Wor A B Z U V W antipole
Supply voltageDC5V & DC8-30V
OutlettypeCable out from side (with metal sleeve)
Output modeOpen Collector circuit output
Voltage output
Push-pull output
Difference outputLong line drive (26LS31)
Long line drive (RT7272)  RS422
Long line drive (26LS31)-Phase ABZ back of UVW
Environmental temperature Operating temperature: -20~+80° (Non icing)
Storage temperature: -25~+85° (Non icing)
Environmental humanity Operating and storage: 35~85%RH (non-condensing)
Protection gradeIP50
Cable length500mm(Can be added)
Shell Aluminium
packageCarton box
Net weight About  140g (with package)
Certification CE






3) Pictures





4) Machine Dimension







Our Factory


company introduction

Shanghai Hengxiang Optical Electronics Co.,Ltd, located on Shanghai, an international city of China, set up in 2001, is a professional manufacturing high-tech corporation, providesresearch and manufacturing ,entity integrating optical,mechanical and electronic design. Now we have finished primary pipelining of encoder manufacture.



    "HengXiang" brand encoder, has ISO9001:2000 Quality Management System Certificate and CE Certification, moreover, we have own invention patents five and utility model patents five, also passed Shanghai New and High-tech AchievementsTransformation Project.


     Our target: Meeting Client's Requirement,Creating Social value,serving clients attentively and Achieving win-win.


     Sincerely welcome all customers to visit our company, to review and custom "HengXiang" brand products .




FAQ before ordering

1) How to select an encoder

Before ordering encoders, you could clearly know which type of encoder you may need.

There are incremental encoder and absoltue encoder, after this, our sale-service department would better work for you.


2) What specifications are requeted before order an encoder?

Encoder type----------------solid shaft or hollow shaft encoder

External Diameter----------Min 12mm, MAX 100mm

Shaft Diameter---------------Min shaft 2.5mm, Max shaft 45mm

Phase & Resolution---------Min 20ppr, MAX 48000ppr

Circuit Output Mode-------you could choose NPN,PNP,Voltage, Push-pull,Line driver, etc

Power Supply Voltage------DC5V-30V


3) How to choose a right encoder by yourself ?

Exact Specification Describtion

Check The Installation Dimensions

Contact Supplier to get more details


4) How many pieces to start ?

1PCS only


5) Why choose "Hengxiang" Brand Encoder


All encoders are designed and developed by our own engineer team since year2008,

and most of the electronic component of encoders are imported from overseas market.

Never let our quality down,because quality is our culture.


6) How long is your lead time?


Short lead time----3 days for samples,7-10days for mass production


7) what is your guarantee policy?

1year warranty  and  life-long technical support



8) Your Company Official Website?


You For More information,please freely visit our official website:http://www.shhxgd.com


9) Where to download encoder datasheet or catalogue?


You could visit our website at http://www.shhxgd.com or contact online sale service to get the latest catalogue files.
